CPU Specifications
Total Cores 24
# of Performance-cores 8
# of Efficient-cores 16
Total Threads 32
Max Turbo Frequency
5.8 GHz
Intelr Thermal Velocity Boost Frequency
5.8 GHz
Intelr Turbo Boost Max Technology 3.0 Frequency
5.6 GHz
Performance-core Max Turbo Frequency
5.4 GHz
Efficient-core Max Turbo Frequency
4.3 GHz
Performance-core Base Frequency
2 GHz
Efficient-core Base Frequency
1.5 GHz
Cache
36 MB Intelr Smart Cache
Total L2 Cache
32 MB
Processor Base Power
65 W
Maximum Turbo Power
219 W
Supplemental Information
Marketing Status
Launched
Launch Date
Q1 24
Embedded Options Available
Yes
Use Conditions
PC/Client/Tablet- Workstation
Memory Specifications
Max Memory Size (dependent on memory type)
192 GB
Memory Types
Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels
2
Max Memory Bandwidth
89.6 GB/s
ECC Memory Supported
Yes
GPU Specifications
GPU Name
Intelr UHD Graphics 770
Graphics Base Frequency
300 MHz
Graphics Max Dynamic Frequency
1.65 GHz
Graphics Output
eDP 1.4b- DP 1.4a- HDMI 2.1
Execution Units
32
Max Resolution (HDMI)
4096 x 2160 @ 60Hz
Max Resolution (DP)
7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)
5120 x 3200 @ 120Hz
DirectX* Support
12
OpenGL* Support
4.5
OpenCL* Support
3.0
Multi-Format Codec Engines
2
Intelr Quick Sync Video
Yes
Intelr Clear Video HD Technology
Yes
# of Displays Supported
4
Device ID
0xA780
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max # of DMI Lanes
8
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations
Up to 1x16+4- 2x8+4
Max # of PCI Express Lanes
20
Package Specifications
Sockets Supported
FCLGA1700
Max CPU Configuration
1
Thermal Solution Specification
PCG 2020C
TJUNCTION
100dC
Package Size
45.0 mm x 37.5 mm
Max Operating Temperature
100 dC
Advanced Technologies
Intelr Gaussian | Neural Accelerator
3.0
Intelr Thread Director
Yes
Intelr Deep Learning Boost (Intelr DL Boost) on CPU
Yes
Intelr Speed Shift Technology
Yes
Intelr Adaptive Boost Technology
Yes
Intelr Thermal Velocity Boost
Yes
Intelr Turbo Boost Max Technology 3.0
Yes
Intelr Turbo Boost Technology
2.0
Intelr Hyper-Threading Technology
Yes
Intelr 64
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intelr SSE4.1- Intelr SSE4.2- Intelr AVX2
Idle States
Yes
Enhanced Intel SpeedStepr Technology
Yes
Thermal Monitoring Technologies
Yes
Intelr Volume Management Device (VMD)
Yes
Security | Reliability
Intel vPror Eligibility
Intel vPror Enterprise- Intel vPror Essentials- Intel vPror Platform
Intelr Threat Detection Technology (TDT)
Yes
Intelr Active Management Technology (AMT)
Yes
Intelr Standard Manageability (ISM)
Yes
Intelr Remote Platform Erase (RPE)
Yes
Intelr One-Click Recovery
Yes
Intelr Hardware Shield Eligibility
Yes
Intelr Control-Flow Enforcement Technology
Yes
Intelr Total Memory Encryption - Multi Key
Yes
Intelr AES New Instructions
Yes
Secure Key
Yes
Intelr OS Guard
Yes
Intelr Trusted Execution Technology
Yes
Execute Disable Bit
Yes
Intelr Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intelr Stable IT Platform Program (SIPP)
Yes
Intelr Virtualization Technology with Redirect Protection (VT-rp)
Yes
Intelr Virtualization Technology (VT-x)
Yes
Intelr Virtualization Technology for Directed I/O (VT-d)
Yes
Intelr VT-x with Extended Page Tables (EPT)
Yes
